Designed with a 120-Volt AC (2HP equivalent) motor, this chain driven sliding gate opener provides exceptional starting torque and continuous operation making it ideal for most applications. Opens gates up to 2,700 lbs. and up to 40 ft. in length. Single Phase Motor. Magnetic limit switches for easy adjustments. For your safety, this model will stop and reverse if encounters an obstruction on closing or opening. Built in adjustable auto-close future. The motor makes the opener comfortable and reliable to operate but up to a certain range of 2700 lbs. This package contains 20 ft. chain and if the capacity exceeds more than 20 ft., extra chain is required to support.
- Opens gates weighing up to 2700 lb. or 40 ft. in length
- Power supply: 120-Volt/60Hz, 2 HP
- Operating time: 0 – 44 seconds
- Absorbed power: AC2700:550-Watt
- Gate moving speed: (7.9 in./second) 20 cm/second
- Maximum gate weight: 1200 kg / 2700 lb.
- Max torque: SCG21H: 35 Nm
- Environmental conditions: from -15°C (5°F) to +40°C (104°F)
- Protection class: IP44
